ITC-M4
Molded-in Threaded Inserts, Thru-Threaded
ITC-M4
Molded-in Threaded Inserts, Thru-Threaded
- Pilot diameter and undercuts allow plastic to flow into grooves providing high pullout resistance.
- Aluminum inserts ideal for light weight designs.
- Aluminum and stainless steel inserts offer lead-free alternative.
仕様
- Thread Code.jp
- M4
- ねじ径
- M4 x 0.7
- ねじ径 x ピッチ
- M4 x 0.7
- ねじの仕様
- 6H per ASME B1.13M
- ファスナー材質
- 300 Series Stainless Steel
- Standard Material
- 300 Series Stainless Steel
- 表面処理
- Passivated and/or tested, Passivated and/or tested per ASTM A380
- Product Category
- Molded-in Threaded Inserts, Thru-Threaded
- CAD Supplier
- PennEngineering® (SI®)
- CADPartID
- 103800
- Thread Type
- ITC
- 下板の材質
- Plastic
- ブランド
- SI
- ファスナーの特徴
- Threaded Internal
- 取付け用機材
- Molded-In
- PEM®製品
- SI
- 製品
- Inserts
- 技術
- Inserts for Plastics
- ユニット
- Metric
- A ± 0.13_mm
- 6.35mm
- C ± 0.13_mm
- 5.74mm
- E Nom._mm
- 6.35mm
- Minor Dia.Max._mm
- 3.42mm
- Minor Dia.Min._mm
- 3.25mm
- S1 Nom._mm
- 1.16mm
- S2 Nom._mm
- 1.57mm
